PREMIUM 1.2367

BS 1.2367

X38CrMoV5-3

PREMIUM 1.2367

X38CrMoV5-3
€co-Präz®
-flat-
PRS / BA
-round-
Logo_Abrams_Ausrufezeichen
STEEL MADE WITH ”STYLE“ !

Standard values

Chemical designation: X38CrMoV5-3
Working hardness: 50-54 HRC
Delivery condition: maximum 229 HB
Chemical composition:
C Si Mn P S Cr Mo V
0.35

0.4
0.3

0.5
0.3

0.5
0

0.03
0

0.02
4.8

5.2
2.7

3.2
0.4

0.6

Technical properties

Hot work steel with excellent toughness, excellent heat resistance and excellent tempering resistance. Good hardenability with high warp-resistance. Can be cooled with water.


Applications

Dies, die inserts, extrusion presses, hot extrusion tools, die casting tools, slides, press mandrels, intermediate sleeves, die holders, profiling dies, profile mandrels, block receivers, hot shear knives, light metal processing, plastic moulds.

Hot work steel with excellent toughness, excellent heat resistance and excellent tempering resistance. Good hardenability with high warp-resistance. Can be cooled with water.

Dies, die inserts, extrusion presses, hot extrusion tools, die casting tools, slides, press mandrels, intermediate sleeves, die holders, profiling dies, profile mandrels, block receivers, hot shear knives, light metal processing, plastic moulds.

Chemical designation: X38CrMoV5-3
Working hardness: 50-54 HRC
Delivery condition: maximum 229 HB
C Si Mn P S Cr Mo V
0.35

0.4
0.3

0.5
0.3

0.5
0

0.03
0

0.02
4.8

5.2
2.7

3.2
0.4

0.6

70 STEEL GRADES IN 32.629 DIMENSIONS

EX WORKS FROM OSNABRÜCK

DELIVERY IN 3-5 WORKING DAYS (SUBJECT TO AVAILABILITY)

WITHOUT MINIMUM ORDER VALUE OR QUANTITY

FROM EUROPE'S LARGEST RANGE OF SEMI-FINISHED PRODUCTS

SPECIAL CUSTOM DIMENSIONS SAWN - MILLED - GROUND
