PREMIUM 1.7131

BS 527 M 17

16MnCr5, (EC80)

PREMIUM 1.7131

16MnCr5, (EC80)
PFS / BA
-flat-
€co-Präz®
-flat-
Logo_Abrams_Ausrufezeichen
HEART AND SOUL IN STEEL!

Standard values

Chemical designation: 16MnCr5, (EC80)
Working hardness (surface): 58-60 HRC
Delivery condition: maximum 217 HB
Chemical composition:
C Si Mn P S Cr
0.14

0.19
0

0.4
1.0

1.3
0

0.025
0

0.035
0.8

1.1

Technical properties

Cold work and plastic mould steel (group of case hardening steel) with the objective of high surface hardness with core toughness. Excellent machinability, good cold hobbing and polishing properties. The tensile strength is a result of the combination of hardened surface and tough core.


Applications

Mechanical engineering, jig construction, plant engineering, apparatus engineering, plastic processing, plastic moulds, synthetic resin moulds, base plates, bending bars, guide columns, gear parts, joint parts, shafts, gears, rods, bevel gears, crown wheels, piston pins, camshafts, bolts, pins, cardan joints.

Cold work and plastic mould steel (group of case hardening steel) with the objective of high surface hardness with core toughness. Excellent machinability, good cold hobbing and polishing properties. The tensile strength is a result of the combination of hardened surface and tough core.

Mechanical engineering, jig construction, plant engineering, apparatus engineering, plastic processing, plastic moulds, synthetic resin moulds, base plates, bending bars, guide columns, gear parts, joint parts, shafts, gears, rods, bevel gears, crown wheels, piston pins, camshafts, bolts, pins, cardan joints.

Chemical designation: 16MnCr5, (EC80)
Working hardness (surface): 58-60 HRC
Delivery condition: maximum 217 HB
C Si Mn P S Cr
0.14

0.19
0

0.4
1.0

1.3
0

0.025
0

0.035
0.8

1.1

70 STEEL GRADES IN 32.629 DIMENSIONS

EX WORKS FROM OSNABRÜCK

DELIVERY IN 3-5 WORKING DAYS (SUBJECT TO AVAILABILITY)

WITHOUT MINIMUM ORDER VALUE OR QUANTITY

FROM EUROPE'S LARGEST RANGE OF SEMI-FINISHED PRODUCTS

SPECIAL CUSTOM DIMENSIONS SAWN - MILLED - GROUND
